WNK9 Series Hygienic pressure transmitter

WNK91 is a hygienic pressure transmitter with display. The material, structure, performance, processing (such as welding, polishing, etc.) and cleaning treatment of the hygienic pressure transmitter meet a series of hygienic requirements. This product adopts high-precision silicon pressure core 316L diaphragm or E+H high-precision ceramic capacitive pressure sensor, which has good stability, no dead angle, and anti-clogging. It is suitable for the measurement of liquid and gas pressure. This product is mainly used in food, daily chemical, medical and pharmaceutical, beverage production, brewing and other fields.

Product name: Hygienic pressure transmitter

Item model number: WNK91

Core Type: Diffused Silicon, Monocrystalline Silicon

Supply voltage: Standard type 10.5~55V DC

Explosion-proof type 10.5~30V DC

Output: 4-20mA、4-20mA+HART、others

Accuracy: 0.1%,0.05%

Range: 0-40KPa...6Mpa (clamp type), 0-40KPa...70Mpa (thread flat film type)

Pressure type: gauge pressure, absolute pressure, seal pressure

Overload pressure: ≤3 times full scale

Working temperature: -40~120℃

Measuring media: All liquids and gases compatible with 316L or Al2O3

Electrical connection: M12

Workpiece material: 316 stainless steel
